Product Description
Biohazards Cabinet, which is meet the laboratories requirements for life science research,clinical or industrial applications. These are manufactured using stainless steel for easy cleaning and maintenance and excellent powder coating finish helps to prevent microbial or bacterial growth.
Technical Specifications
- Air cleanliness : ISO Class 5 / Class 100 / M 3.5 AREA
- Air Velocities : 0.45 0.05 mps (90 20 FPM)
- Air Flow : Vertical
- Noise Level : Minimum
- Vibration Level : Minimum
- POWER SUPPLY : 240V AC, 1-, 50HZ
- MOC : GI Powder Coated / SS-304 / SS-316 / Combination
- Sliding type SS Work Top
- Sash (Shutter) : Vertical rising of vertical opening
- Sash monument with counter weight balance mechanism , Made of polycarbonate / toughened glass
- Two Stage filtration
- EU7 - Intermediate Filter (95% down to 3 micron)
- EU14 - HEPA Filter - Supply / Exhaust (99.999% down to 0.3 micron)
- Statically & Dynamically balanced Motor-blower with isolator to reduce noise level
- Fluorescent Lights with milky diffuser
- Differential Pressure Gauges : 02 Nos. (HEPA & Pre-Filter)
- ON/OFF Switches (BL / FL)
- DOP Port
- DQ, IQ, OQ, PQ Documentation
Options and Accessories
A wide range of configurations to suit any containment application: -
- Once through System (100% Exhaust)
- Pass Box for arrangement material transfer
- Gloves arrangement for isolator design
- Velocity display with High / Low Alarms
- Filter chocking alarms
Model | Working Area( wxdxh) | Overall dimension WXDXH |
PBSC-22 | 610 x 610 x 610 | 760 x 850 x 1980 |
PBSC-32 | 915 x 610 x 610 | 1070 x 850 x 1980 |
PBSC-42 | 1220 x 610 x 610 | 1370 x 850 x 1980 |
