Product Description
A1 Type Class II Biological Safety Cabinet, which is meet the laboratories requirement for life science research, clinical or industrial applications. these are manufactured ushing stainless steel for easy cleaning and maintenance and excellent powder coating finish helps to prevent microbial or bacterial growth. Specification Working Area 3 Ft., 4 Ft., 5 Ft., 6 Ft. Bio safety Type Class II (Type: A2 / Type: B1 / Type: B2) Cleanliness ISO CLASS 5 OR CLASS 100 Velocity at Grill 90 20 FPM MOC S.S.-304, HEPA Filter HEPA Filters down to 0.3mic. particulate at an efficiency of 99.999% duly tested Work Top Perforated Work (SS-304) Top Front Sash Sliding Door with Counter weight Accessories 1. GAS / AIR Cock2. DOP Port Blower Assembly Dynamically and statically balanced in-built motor and blower Electrical 1) On/Off Panel2) Diffused Fluorescent Light3) U V Light with Hour Meter4) Auxiliary Socket 15 Amp. Leveling Pads For leveling and Positioning of the Unit Noise Level Less than65db@1.5mtr. distance Powder supply 230 V, 50Hz, Single Phase
|
Working Area
|
:
|
As Specified Below
|
|
|
Bio safety Type
|
:
|
70% Air Re-Circulated & 30% Air Exhaust
|
|
Cleanliness
|
:
|
ISO CLASS 5 OR CLASS 100
|
|
Velocity at Grill
|
:
|
90 20 FPM
|
|
MOC
|
:
|
S.S. 304
|
|
Grill for HEPA
|
:
|
Made out of SS 304
|
|
HEPA Filter
|
:
|
HEPA Filters down to 0.3 Mic. Particulate at an Efficiency of 99.99% duly tested on DOP aerosol method
|
|
Exhaust HEPA Filter
|
:
|
SEMI HEPA Filters down to 0.3 Mic. Particulate at an Efficiency of 99.99% duly tested on DOP aerosol method
|
|
Work Top
|
:
|
Perforated Work (SS-304) Top
|
|
Front Sash
|
:
|
Sash Door Provided with Toughen Glass
|
|
Blower Assembly
|
:
|
Statically and Dynamically Balanced Motor Blower, Designed for Exhaust of sufficient capacity and Static Pressure to take care of airflow requirement for entire life of HEPA.
|
|
Electrical
|
:
|
1) On/Off Panel (BL / UV / FL)
2) Diffused Fluorescent Light
3) U.V. Light with Hour Meter
4) Auxiliary Socket
|
|
Pressure Gauge
|
:
|
MEGNAHELIC GAUGE (Analog)
|
|
Power supply
|
:
|
230 V, 50Hz, Single Phase
|
|
Documentation
|
:
|
DQ, IQ, OQ Report (Our Factory Tested Only)
|
FAQs of A1 Type Class II Biological Safety Cabinet:
Q: What is the material used in the construction of the A1 Type Class II Biological Safety Cabinet?
A: The A1 Type Class II Biological Safety Cabinet is constructed entirely from stainless steel, including its frame material.
Q: What type of filter does the A1 Type Class II Biological Safety Cabinet feature?
A: It features mini pleated HEPA filters that can capture particulates down to 0.3 microns at an efficiency of 99.997% (EU14), duly tested using DOP testing.
Q: What voltage is required to operate the A1 Type Class II Biological Safety Cabinet?
A: The cabinet operates on 230 volts, single-phase power, with a frequency of 50Hz.
Q: What industries and applications are ideal for using the A1 Type Class II Biological Safety Cabinet?
A: This biological safety cabinet is suitable for pharmaceutical industries, laboratories, microbiology setups, and life science laboratories.
Q: Can the dimensions and specific features of the A1 Type Class II Biological Safety Cabinet be customized?
A: Yes, the dimensions (L*W*H) and specific features such as lighting and weight are customizable based on individual requirements.
