Technical Specifications
Air cleanliness : ISO Class 5 / Class 100 / M 3.5 AREA
Air Velocities : 0.45 0.05 mps (90 20 FPM)
Air Flow : Horizontal / Vertical
Noise Level : Less than 65 dB
Vibration Level : Minimum
POWER SUPPLY : 230V AC, 1-, 50HZ
MOC : GI Powder Coated / SS-304 / SS-316
Two Stage filtration
EU7 - Intermediate Filter (95% down to 3 micron)
EU14 - HEPA Filter - Supply / Exhaust (99.999% down to 0.3 micron)
Statically & Dynamically balanced Motor-blower with isolator to reduce noise level
Fluorescent Lights
UV Light with house meter (interlocked with Door)
When Door will be Open, UV OFF; Door in Close, UV will ON
Differential Pressure Gauges : 01 No. (HEPA Filter)
ON/OFF Switches (BL / FL)
DOP Port
DQ, IQ, OQ, PQ Documentation
Options and Accessories
A wide range of configurations to suit any containment application: -
Rigid Barrier (Flexible PVC Strip / Poly carbonate / Acrylic Sheet)
Velocity display with High / Low Alarms
Filter chocking alarms
